1U Firewall Server 6 LAN
Feature:
- 1U 19" Structure Network Security Platform;
- Support 3th Generation Core i3 or i5 or i7 LGA1155;
- Max: DDR3 1333 or 1600 16G;
- Support 1*MSATA, 1*CF slot, 1*2.5" HDD;
- Support 1*Mini PCIE, WIFI or Bluetooth;
- Support 6*Intel 1000M LAN; (2*Intel i350 Gbe fiber port Optional);
- 1U 19" Structure Network Security Platform;
- Support 3th Generation Core i3 i5 i7 LGA1155;
- Max:DDR3 1333/1600 16G;
- Support 1*MSATA,1*CF slot,1*2.5" HDD;
- Support 1*Mini PCIE,WIFI/BT;
- Support 6*Intel 1000M LAN(2*Optical Fiber Ports optional);
Specification | |
Model | NS-1U8L (B75) |
Color | Black |
Shell Material | Good quality of cold-rolled sheet |
Processor | Intel Core i3 3220 (dual core, 4 threads, 3.3 GHz) |
Intel Core i5 3450 (quad core, 4 threads, 3.1 GHz, turbo boost 3.5 GHz) | |
Intel Core i7 3770 (quad core, 8 threads, 3.4 GHz, turbo boost 3.9 GHz) | |
Chipset | Intel B75 |
Memory | Support 2*DDR3 1333/1600 MHz, Max: 16 GB |
Display Port | 1*VGA |
Front I/O Port | 1*RJ45 COM (support Console), 2*USB2.0, 6*Intel 1000M LAN |
Back I/O Port | 1*VGA, 1*Power Switch, 1*AC power port |
Expansion Slot | 1*MINI PCIE (Support MSATA) |
1*MINI PCIE (WIFI/Bluetooth optional) | |
LAN | 6*Intel 82583V LAN (2*Intel i350 Gbe fiber port Optional) |
Storage | 1*MSATA |
1*CF Slot | |
1*2.5" SATA HDD (2*2.5" SATA HDD optional) | |
Power Supply | 110～240V/50～60Hz AC Input |
Work Temp | -10℃ ～ +50℃ |
Work Humidity | 5% ～ 95% non-condensing |
Dimension | 440 * 250 * 44.5mm |
Weight | 3.4kg |
Application | Firewall, VPN, Network Server, Network Security, Router and etc. |
Outstanding computing performance
Standard 1U rack server,supports computer-intensive and cloud applications saves energy,lowers TCO,simplifes management and maintenance.
Support Intel Core i3/i5/i7 processor sachieving high performancefor compute-intensive
