J1900 Quad Core Fanless IPC With 1*PCI Slot
- J1900 4 core 4 threads CPU IPC
- Onboard DDR3L 1333 4GB RAM
- 1*VGA,1*HDMI DUAL Display
- 10*COM（2*RS232/422/485 Optional）
◇1*PCI Slot, Max length of expansion card:168 mm
- OS：
IBOX-301 Plus is a fanless All aluminum industrial embedded computer with1x32bit PCI expansion slots. The expansion slot Max. Can support the length of expansion card：168 mm. Powerd by onboard Intel® Celeron® quad core processor J1900 2.0GHz lower power 10W. can meet most industrial control applications.
A convenient design of Onboard DDR3L 1333 4GB RAM,its compact chassis can accommodate 1*MSATA Slot,1*2.5" HDD hard drives to expand your storage capacity.and maximize the stability and storage space.supports 1*VGA,1*HDMI HD Dual display player and dual gigabit LAN ports design,10xLED is convenient to detect the work of each interface . Otherwise DC 9～36V wide voltage Input,Support positive pole and negative electrode connect reversely protection.
Work Humidity
| Specification | IBOX-301 Plus |
| Color | Blue + Grey |
| Processor | Intel Celeron J1900(Quad core quad threading,1.99G,TDP:10W) |
| RAM | Onboard DDR3L 1333 4GB RAM |
| Storage | 1*MSATA Slot,1*2.5" HDD |
| Display Chip | 2*Intel 82583V/i211-AT 10/100/1000M LAN |
| Expansion Slot | 1*PCI Slot(32bit) |
| 1*MINI PCIE Slot(Support WIFI/Bluetooth) | |
| 1*MINI PCIE Slot(Support WIFI/Bluetooth/3G/4G Optional),Embedded SIM slot | |
| 1*MINI PCIE Slot(Support MSATA) | |
| Input Voltage | DC 9～36V wide voltage Input,Support positive pole and negative electrode connect reversely protection |
| Work Temp | 0℃ ～ +50℃(Commercial HDD),-20℃ ～ +60℃ |
| 5% ～ 95% non-condensing | |
| Dimension | 185 * 175 * 100 mm【Not include the brackets】 |
| Net Weight | 2.5 kg【Not include the brackets】 |
Learn more about IBOX-301Plus Model, a Fanless Industrial Computer J1900 Quad Core Embedded Dual Lan Mini Pc With Pci Express Slot welcome consult
